Stainless Steel Hollow Sections Rectangular

GENERAL INFORMATION

Standard tubes suitable for general applications, obtained from annealed strips, not heat treated, tested on demand outside surface brushed or polished.

Tubes in common, multiple or fixed lengths.

Material austenitic stainless steel grade 304 according to ASTM A240 or 1.4301 according to EN10088-2, other grades are available upon request.

Reference standards: ASTM-554, EN10219-2

Stainless steel hollow sections are durable with excellent properties for formability and toughness, with excellent corrosion resistance. Stainless steel hollow sections are aesthetically elegant and hygienic products. The combination of strength with fire resistance also offers considerable advantages over carbon steel in all kinds of structures

SIZES TABLE

Thickness
Dimensions mm 1 1.2 1.5 2 3 4
Kg / m
16×11 0.405 0.482 0.595
25×15 0.610 0.727 0.902 1.186
30×20 0.767 0.917 1.139 1.501
40×20 0.923 1.103 1.372 1.812
45×30 1.405 1.749 2.315
50×20 1.081 1.293 1.608 2.128
50×25 1.174 1.405 1.749 2.315
50×30 1.236 1.479 1.841 2.438 3.584
50×40 1.663 2.071 2.744 4.042
60×20 1.479 1.841 2.438
60×30 1.663 2.071 2.744 4.042
60×40 1.855 2.311 3.065 4.523
70×20 1.663 2.071 2.744 4.042
70×30 1.855 2.311 3.065
80×40 2.225 2.774 3.681 5.448 7.165
100×20 2.225 2.774 3.681 5.448
100×40 3.251 4.318 6.402 8.438
100×60 3.713 4.934 7.327 9.671
120×80 6.20 9.24 12.20

GENERAL INFORMATION

Standard tubes suitable for general applications, obtained from annealed strips, not heat treated, tested on demand outside surface brushed or polished.

Tubes in common, multiple or fixed lengths.

Material austenitic stainless steel grade 304 according to ASTM A240 or 1.4301 according to EN10088-2, other grades are available upon request.

Reference standards: ASTM-554, ΕΝ10296-2

SIZES TABLE

Thickness
Dimensions mm 1 1.2 1.5
Kg / m
16×11 0.405 0.482 0.595
25×15 0.610 0.727 0.902
30×20 0.767 0.917 1.139
40×20 0.923 1.103 1.372
45×30 1.405 1.749
50×20 1.081 1.293 1.608
50×25 1.174 1.405 1.749
50×30 1.236 1.479 1.841
50×40 1.663 2.071
60×20 1.479 1.841
60×30 1.663 2.071
60×40 1.855 2.311
70×20 1.663 2.071
70×30 1.855 2.311
80×40 2.225 2.774
100×20 2.225 2.774
100×40 3.251
100×60 3.713
120×80
Thickness
Dimensions mm 2 3 4
Kg / m
16×11
25×15 1.186
30×20 1.501
40×20 1.812
45×30 2.315
50×20 2.128
50×25 2.315
50×30 2.438 3.584
50×40 2.744 4.042
60×20 2.438
60×30 2.744 4.042
60×40 3.065 4.523
70×20 2.744 4.042
70×30 3.065
80×40 3.681 5.448 7.165
100×20 3.681 5.448
100×40 4.318 6.402 8.438
100×60 4.934 7.327 9.671
120×80 6.20 9.24 12.20
